| Parameter Name | Parameter Value | Unit |
| Forklift Model | FRTA70S | / |
| Brand | BOJUNCTION | / |
| Forklift Size | 5030*2190*2810 | mm |
| Fork Size | 1220*50*150 | mm |
| Rated Load | 7000 | kg |
| Engine Model | Diesel | / |
| Engine Power | 42(Optional) | kw |
| Load Center Distance | 500 | mm |
| Weight | 8200 | kg |
| Minimum Ground Clearance | 356 | mm |
| Mast Tilt Angle (Front/Rear) | 8 degree/10 degree | degree |
| Max Driving Speed (Full load/Empty load) | 30/35 | km/h |
| Max Climbing Angle(Full load/Empty load) | 20/30 | degree |
| Fork Standard Lifting Height | 3000 | mm |
| Customized Service | Configuration, Engine,Tire,Color,etc. | |
Forklift Gantry
*Widened and thickened gantry,stronger and more reliable overall structure.
*Hidden pipeline layout provides a wide-open view.
*Equipped with upper and lower cushioning, more smoother and safe during work.
Diesel Engine
Use China Top Brand Diesel Engine: Quanchai etc.
High-speed Grars
Equipped with dual high-speed grars, up to 35km/h (22miles/h).
It is especially suitable for outdoor work.
Customized service
Accept customized service from engine,gearbox, configuration,tires,etc.
Modular production line with QC checkpoint at each stage.
Ultra-short Design
Our latest model, the 7th generation, with extreme shortest integral body 3.3m only, (ordinary rough terrain forklift is about 4.0 meters). making it more flexible in the narrow space. Full size: 3.3*1.95*2.15m.the unique design owns several national patents.
